Seattle Opera.

Lucia di Lammermoor



Stage Director: Tomer Zvulun
Conductor: Bruno Cinquegrani
Set Designer: Robert Dahlstrom
Costume Designer: Deborah Trout
Lighting Designer: Robert Wierzel
Scenery Period/Style: Timeless
Scenery: 2008, added elements in 2010
Scene Shop: Seattle Opera Scenic Studios
Costume Period/Style: Mid 19th Century Northern Europe
Year Costumes Built: 2010
Costume Shop: Seattle Opera Costume Shop
Supertitles: Jonathan Dean


View Lucia di Lammermoor in the Performance Archive



Scenery and Services Fee: $62,000.00
Director: First opportunity to provide aritst's services or name an assistant. Royalty might apply.
Set Designer Royalty: Included
Number and size of truck(s): 3 - 53' Logistic post with Air-Ride
Insured set value: $500,000.00
Load-out/in costs: Deposit of $10,000.00 required. Actual costs will be calculated and SO will invoice/refund the difference.
Technical Supervisors:
  • Provided by Seattle Opera.
  • Required for the initial load-in, set-up and load-out.
  • Expect 2 days to load-in this scenery and 1 day to strike and load-out.

NOTE: The quoted costs are subject to change. Final costs will be set when a contract is requested.


  Set-Up Running Strike
Stage Carpenters: 16 8 20
Stage Properties Crew: 4 4 4
Stage Electricians: 14 6* 14
Stage Fly Men: 2 2 2
Approximate time (hours): 34 hours  N/A 13 hours

* Does not include board operators or follow spots

View Scenery Technical Drawings


Minimum width: 91' (does not include offstage storage)
Minimum depth: 51' for set, 56' to R/P
Minimum number of line sets: 15 (does not include masking or electrics)
Furthest upstage flying piece: 54' 9" (not including R/P)
Height of tallest flying piece: 40'


  • Main catwalks of set are hung from a total of 10 1-ton chain hoists.
    An additional 7 1-ton chain hoists were used for assembly.
    An additional 2 1-ton chain hoists were used for offstage assembly.
    Additionally – Chandelier on 2 point hoists,
    Gate storage on 2 point hoists,
    Window wall storage on 2 point hoists.
  • Stock escapes are included in the rental if available.
  • Stock equipment is NOT included in the rental price. Stock equipment includes, but is not limited to, the following:
    • All black masking
    • Point Hoists



Total Costume Rental: $22,900.00


  • Costume rental fee
  • Designer Royalty
  • Packing charges
  • Cleaning

Not Included:

  • Refundable damage deposit
  • Shipping
  • Insurance Certificate

COSTUME Information

Principal Women (6 costumes)
4) Lucia (x2 - double cast)
2) Alisa

Principal Men (7 costumes)
2) Edgardo (x2 - double cast)
2) Enrico (x2 - double cast)
1) Normanno
1) Raimondo
1) Arturo

Chorus Women (18 costumes)
Act II scene 2 Party:
18) Ballgowns

Act III scene 2:
All add cloaks and bonnets

Chorus Men (22 bodies, 44 costumes)
Act I scene 2:
11) Peasants
11) Servants (note: some "Servant" men repeat pieces with Act II looks)

Act II scene 2 Party:
16) Formal Tailsuits
6) Uniforms

Act III scene 2:
All add cloaks and hats

Super Women (5 bodies, 6 costumes)
1) Love-cursed Bride
1) Cavalier Woman
2) Maids
2) Party guests

Super/Actor Men (13 bodies, 13 costumes)
1) Major Domo
7) Normanno Guards
4) Liveried Servants
1) Cavalier Man
Act III scene 2 all add cloaks

Super Children (2 costumes)
1) Girl Party Guest
1) Boy Party Guest

All rental information and pricing is subject to change without notice. Material at this site is the property of Seattle Opera and is presented solely for informational and educational purposes. It is not to be reproduced or used for any other purpose without the written consent of Seattle Opera.


Supertitles are also available to rent for Lucia di Lammermoor. Please send all inquiries to
